Target products
Cold filling for various sample bottles, e.g. ampoules, dropper bottles, roll-on bottles
Output
25–50 pieces per minute
Power supply
220v 50Hz 5Kw
Compressed air
0.6-0.8Mpa
Features:
1. Suitable for filling liquids of different viscosities.
2. Molds and conveyor made of special material to prevent scratches on bottles during production.
3. Vacuum dust extraction; cleaning process will not compromise the cleanliness of filling stations.
4. Servo-controlled high-precision ceramic filling pump with no dripping and accurate dosing.
5. Bottle and cap feeding speed automatically synchronized with filling speed. Simplified operation with independent station adjustment for maintenance and commissioning.
6. Tankless design; storage tank connected to filling pump via sanitary silicone hose with quick-disconnect fittings for fast disassembly, cleaning and sterilization.
7. All manually adjustable parts are equipped with graduated scales for parameter archiving.
8. Robotic pre-capping at cap feeding station to ensure proper cap seating.
9. Safety guard doors with safety interlock system; automatic stop upon door opening to protect operators.
10. Controlled by PLC + touchscreen; HMI language can be programmed according to customer requirements.
2. Molds and conveyor made of special material to prevent scratches on bottles during production.
3. Vacuum dust extraction; cleaning process will not compromise the cleanliness of filling stations.
4. Servo-controlled high-precision ceramic filling pump with no dripping and accurate dosing.
5. Bottle and cap feeding speed automatically synchronized with filling speed. Simplified operation with independent station adjustment for maintenance and commissioning.
6. Tankless design; storage tank connected to filling pump via sanitary silicone hose with quick-disconnect fittings for fast disassembly, cleaning and sterilization.
7. All manually adjustable parts are equipped with graduated scales for parameter archiving.
8. Robotic pre-capping at cap feeding station to ensure proper cap seating.
9. Safety guard doors with safety interlock system; automatic stop upon door opening to protect operators.
10. Controlled by PLC + touchscreen; HMI language can be programmed according to customer requirements.
